22 Feet Truck Dimensions in India: Payload, Models in 2026, Best Use Cases

A 22 feet truck sits at a sweet spot that most logistics planners underestimate. It carries two to three tonnes more than a standard 20-footer, costs only marginally more to operate, and still clears most state road restrictions without special permits. If you are sizing up between a 20 ft and a 24 ft truck, you may be overlooking the one that fits your route best.

Dimensions of 22 Feet Truck in India

A standard 22 feet truck in India has the following typical external dimensions:

• Length: 22 feet (6.7 metres)

• Width: 7.5 feet (2.3 metres)

• Height: 8 feet (2.4 metres)

These figures apply to a standard closed container body. Open-body (platform) variants share the same cargo length but have no fixed roof, allowing for taller loads and side or top unloading.

Internal cargo dimensions (closed container, typical):

• Internal length: ~21.3 feet (6.5 metres)

• Internal width: ~7.2 feet (2.2 metres)

• Internal height: ~7.5 feet (2.3 metres)

• Cargo volume: approximately 1,151 CFT (cubic feet)

That 1,151 CFT is roughly equivalent to the contents of a fully packed 3 BHK apartment: furniture, appliances, and boxes included. Or 22–27 standard FMCG pallets.

Here is what most shippers do not account for: the 22 ft body is available on both the 16-tonne GVW and the 17.5-tonne GVW chassis and the legal payload difference between those two options is nearly 1,000 kg. Always confirm which chassis your truck is built on before loading.

For a full comparison of all truck sizes available in India, see our truck dimensions in feet in India guide.

22 Feet Truck Payload Capacity

Almost all 22 feet trucks operating in India are single-axle (SXL), 6-wheeler configurations. Payload range depends on the specific chassis:

• Lower-GVW variants (GVW ~16,100 kg): Payload of approximately 9,500–10,800 kg

• Higher-GVW variants (GVW ~17,500–18,500 kg): Payload of up to 11,500 kg

For example, the Ashok Leyland Ecomet 1615 HE (22 ft) offers 10,800 kg payload at a GVW of 16,100 kg, while the Eicher Pro 3015XP (22 ft) delivers a class-leading 11,500 kg payload at a GVW of 17,500 kg. The BharatBenz 1917R (22 ft) matches that GVW at 18,500 kg with a payload of 10,886 kg.

GVW (Gross Vehicle Weight) is the total permissible weight of the truck plus its full load. The difference between GVW and the truck's kerb weight gives you your legal payload ceiling.

SXL (Single Axle) means one rear axle with four tyres. The standard configuration on all 22 ft ICV trucks.

The most common mistake with 22-footers: Operators assume the bigger body means a bigger legal load. It does not, it means more cubic volume, not necessarily more payload. If you are loading dense goods like ceramic tiles, packaged liquids, or auto components, you can easily exceed the axle limit well before the container is full. Check density before dispatch, every single time.

Best 22 Feet Trucks in India : Top Models in 2026

The Eicher Pro 3015XP (22 ft) stands out for operators who need maximum payload in the ICV class. Its 7-speed gearbox, 180 HP E494 engine, and 11,500 kg capacity give you the best tonne-per-rupee ratio at this length. For fleet operators prioritising low maintenance and German engineering, the BharatBenz 1917R is a serious alternative with a slightly higher GVW rating.

Open Body vs Closed Container : Which One to Choose?

Both configurations are widely available for the 22 ft chassis:

Open Body (platform/flatbed)

No roof or fixed sides, with removable iron rails or a flat deck. The right choice for steel pipes, granite slabs, construction materials, timber, and any cargo that needs crane or top-loading. You can stack above the rail height for weather-resistant goods, which no container can accommodate.

Closed Container (box body)

Fully enclosed steel or reinforced aluminium body with rear shutter or swing doors. Protects cargo from dust, rain, pilferage, and temperature swings on multi-day, multi-city runs. The standard choice for FMCG, electronics, pharmaceuticals, packaged foods, and garments.

One-line decision rule: If the cargo is weather-sensitive or high-value and your run is over 400 km, go closed container. If the cargo is dense, weather-resistant, or irregular in shape, go open body.

22 Ft Truck Best Use Cases

FMCG Regional Distribution (300–700 km corridors)

A 22 ft closed container is a staple on routes connecting regional distribution centres to city stockpoints. The extra volume over a 20-footer lets you consolidate an additional pallet tier, reducing the number of trips per week.

Pharmaceuticals and Healthcare Logistics

Insulated or temperature-controlled box bodies are frequently built on 22 ft ICV chassis. The vehicle's ICV classification keeps it accessible in most city distribution zones without time-band restrictions that apply to HCVs.

White Goods and Consumer Electronics

Air conditioners, large-screen TVs, refrigerators, and washing machines are high-volume, medium-weight goods that fill a 22 ft container comfortably without breaching the payload limit. The ideal scenario for this size.

Textiles and Garments (B2B)

Baled fabric rolls, packaged garments, and readymade export-quality goods travel well in 22 ft closed containers. The enclosed body prevents dust contamination, and the volume allows full roll stacking without secondary packaging.

E-commerce Hub-to-hub Movements

Mid-tier e-commerce fulfilment operations use 22 ft trucks to shuttle sorted parcels between state hubs on overnight lanes. The closed body and shutter doors allow fast rear-load and rear-unload at dock-level platforms.

Household Relocations

For a well-packed large apartment move with a full modular kitchen, heavy wardrobes, and double beds, the 22 ft container typically handles everything in a single load where a 20 ft might fall short.

3 Questiones YOU Need to Answer Before Buying

Answer these three questions with a YES before booking or buying:

1. Does your cargo volume regularly hit 1,000–1,150 CFT?

If yes, the 22 ft is your match. If your loads consistently run under 900 CFT, the 20 feet truck will serve you at a lower per-trip cost.

2. Does your cargo weigh between 9 and 11.5 tonnes per load?

That is the sweet spot for a 22 ft SXL. If you are regularly loading above 12 tonnes, the 22 ft will not legally accommodate it — look at the 24 feet truck with a multi-axle option.

3. Does your route include city delivery zones with time-band restrictions?

A 22 ft ICV truck is not classified as an HCV (Heavy Commercial Vehicle) under most state rules, so it typically avoids daytime city-entry restrictions that apply to larger trucks. Confirm your specific state's rules before planning urban delivery schedules.

If your loads are lighter and your routes are shorter, the 20 feet truck dimensions guide will help you compare. For heavier or longer loads, see our 24 feet truck guide.

Legal Limits and Permits You Need to Know

Under the Motor Vehicles Act, 1988 and the 2018 MoRTH axle load revision, these limits apply to a standard 22 ft SXL (6-wheeler) ICV truck:

Maximum GVW: Up to 18,500 kg for two-axle rigid trucks (revised 2018 limits)

Maximum vehicle width: 2.5 metres (8.2 feet). All standard 22 ft trucks comply

Maximum vehicle height: 4.75 metres. No standard 22 ft closed container exceeds this

Maximum rigid truck body length: 12 metres (39.4 feet). A22 ft (6.7 m) body is well within this

No special permit is required for a 22 ft closed container or open body truck under standard cargo conditions. ODC (Over Dimensional Cargo) permits apply only when the load protrudes beyond the vehicle's registered dimensions.

Overloading fines under the revised Motor Vehicles Act start at ₹20,000 for the first excess tonne and ₹2,000 per additional tonne. Repeat violations can result in vehicle detention and fitness certificate suspension. A cost no fleet can afford.

Quick Checklist for Buying 22 ft Truck

• Confirm your cargo's weight and volume against the specific model's registered payload. Body size alone is not enough

• Choose body type (open or closed) based on your cargo sensitivity and route length before booking

• Verify GVW compliance for toll calculations on your specific route. Toll charges are GVW-linked

• Ask for the vehicle's fitness certificate, PUC, and insurance papers before loading

• For overnight or 500+ km runs, confirm driver availability and planned rest stops

• Calculate EMI options if purchasing. Most 22 ft ICV trucks qualify for commercial vehicle loans at 8–12% interest; use TruckOnWheels' EMI calculator to model monthly outgo
